150W GPU 및 Intel® Core™ Ultra 200S 시리즈 프로세서를 지원하는 견고한 엣지 AI 플랫폼

Nuvo-11160GC Series 150W GPU 및 Intel® Core™ Ultra 200S Series 지원 팬리스 컴퓨터 (New!)

Supports Intel® Core™ Ultra 200 Series 24C/24T 35W/65W LGA1851 CPU
Supports NVIDIA® RTX series GPU card up to 150W
Rugged, -25°C to 60°C wide temperature operation
5x 2.5GbE and 1x GbE ports with optional PoE+ (ports 3~6)
1x optional 10GBASE-T Ethernet
8x USB 3.2 Gen2 Type-A ports
4-CH isolated DI and 4-CH isolated DO
MezIO® interface for easy function expansion

Overview

Introduction

Neousys의 산업용 Fanless PC Nuvo-11160GC는 인텔®Core™Ultra 200S 시리즈 프로세서를 기반으로 구축된 Neousys의 최신 견고하고 넓은 온도의 엣지 AI 플랫폼으로, 최대 150W의 NVIDIA® RTX™ GPU 카드를 지원합니다. 고성능 밀도와 포괄적인 I/O 연결성을 갖춘 이 제품은 AI 기반 비전 검사, 비디오 분석 및 자율 이동 로봇과 같은 실내외 환경에서 고정 및 모바일 배포 환경 모두에서 까다로운 엣지 AI 애플리케이션에 이상적입니다.

까다로운 실제 애플리케이션을 위해 설계된 산업용 Fanless PC Nuvo-11160GC는 필요한 센서와 제어 장치의 연결을 단순화하고 광범위한 I/O 연결을 제공하며, 컴팩트한 폼 팩터를 통해 공간 제약이 있는 환경에서도 배포할 수 있습니다. 비전 기반 로봇 안내, AI 기반 비전 검사, 비디오 분석과 같은 고정된 사용 사례를 위해 8개의 USB 3.2세대 포트와 6개의 GbE 포트를 제공하며, 공장 자동화 통합을 위한 4-CH 절연 DI 및 4-CH 절연 DO 포트, 고bandwidth 통신을 위한 옵션인 10GbE 포트를 제공합니다. 더 큰 I/O와 기능을 위해 특허받은 MezIO® 인터페이스는 유연한 확장을 가능하게 합니다: MezIO®-U4는 4개의 USB 3.1 포트를 추가하고, MezIO®-G4는 4개의 GbE 포트를 추가하며, MezIO®-D330은 16-CH DIO를 추가합니다.

AMR 및 실외 배달 로봇과 같은 더 까다로운 모바일 로봇 애플리케이션을 위해, 옵션으로 내장된 PoE+ 기능은 GigE 카메라 배포를 간소화하고 미니 PCIe 슬롯은 원격 작동을 위한 4G/5G 모듈 확장을 지원합니다. 특허받은 분리형 카세트 디자인과 업그레이드된 GPU 냉각 팬이 특징인 입증된 열 설계는 -25°C에서 60°C의 넓은 온도 범위에서 신뢰할 수 있는 성능을 보장하여 야외 환경에 적합한 suited을 제공합니다. 전력 효율 측면에서 인텔® Core™ Ultra 200S는 이전 세대에 비해 전력 소비가 80%에 불과하면서도 1.2배 더 높은 CPU 성능을 제공하여 모바일 로봇의 배터리 내구성을 연장할 수 있습니다.

최신 인텔® Core™ Ultra 200S 플랫폼과 최대 150W 블랙웰 GPU 지원, 견고한 넓은 온도 설계, 유연한 입출력 확장 기능을 컴팩트한 공간에 통합한 산업용 Fanless PC Nuvo-11160GC는 고정 및 모바일 애플리케이션 모두에 이상적인 엣지 AI 플랫폼입니다.

The Nuvo-11160GC is Neousys’s latest rugged, wide-temperature edge AI platform built on the Intel® Core™ Ultra 200S series processor with support for NVIDIA® RTX™ GPU cards up to 150W. With high-performance density and comprehensive I/O connectivity, it is ideal for demanding edge AI applications across both fixed and mobile deployments in indoor and outdoor environments, such as AI-driven vision inspection, video analysis and autonomous mobile robots.

Designed for demanding real-world applications, the Nuvo-11160GC simplifies the connection of required sensors and control devices with extensive I/O connectivity, while its compact form factor enables deployment in space-constrained environments. For stationary use cases such as vision-based robotic guidance, AI-driven vision inspection, and video analysis, it offers 8x USB 3.2 Gen 2 ports and 6x GbE ports for multi-camera setups, 4-CH isolated DI and 4-CH isolated DO for factory automation integration, and an optional 10GbE port for high-bandwidth communication. For greater I/O and functionality, the patented MezIO® interface enables flexible expansion: the MezIO®-U4 adds 4 additional USB 3.1 ports, the MezIO®-G4 adds 4 additional GbE ports, and the MezIO®-D330 adds 16-CH DIO.

For more demanding mobile robots applications such as AMRs and outdoor delivery robots, the optional built-in PoE+ capability simplifies GigE camera deployment, while mini PCIe slots support 4G/5G module expansion for remote operation. A proven thermal design, featuring the patented segregated cassette design with an upgraded GPU cooling fan, ensures reliable performance across a wide temperature range of -25°C to 60°C, making it well-suited for outdoor environments. On the power efficiency side, the Intel® Core™ Ultra 200S delivers 1.2x higher CPU performance while consuming only 80% of the power compared to the previous generation, enabling longer battery endurance for mobile robotics.

By integrating the latest Intel® Core™ Ultra 200S platform with up to 150W Blackwell GPU support, a rugged wide-temperature design, and flexible I/O expansion within a compact footprint, the Nuvo-11160GC is an ideal edge AI platform for both stationary and mobile applications.

#Nuvo-11160GC #산업용PC #Fanless PC #MeZIO #Intel Core Ultra 200 #AMR #AI 비전 검사

Specifications

System Core
Processor	Supports Intel® Core™ Ultra 200 series CPU (LGA 1851 socket), 35W and 65W TDP – Intel® Core™ Ultra 9 285/285T – Intel® Core™ Ultra 7 265/265T – Intel® Core™ Ultra 5 245/245T
Chipset	Intel® Q870E Platform Controller Hub
Graphics	Integrated Intel Xe LPG Graphics
AI Engine	Integrated Neural Processing Unit
Memory	Up to 128 GB DDR5 6400 SDRAM (two SODIMM slots)
AMT	Supports Intel vPro/ AMT 16.0
TPM	Supports dTPM 2.0

I/O Interface
Ethernet	5x 2.5G Ethernet by I226-IT and 1x 1G Ethernet by I219-LM with screw-lock 1x optional 10GBASE-T Ethernet
PoE+	Optional IEEE 802.3at PoE+ PSE for Port 3 ~ Port 6. 100W total power budget
USB 3.2	8 x USB 3.2 Gen2 ports
Isolated DIO	4-CH isolated DI and 4-CH isolated DO
Video Port (Integrated Graphics)	1x HDMI™, supporting 3840 x 2160 resolution 2x DisplayPort, supporting 4096 x 2304 resolution
Serial Port	2x software-programmable RS-232/ 422/ 485 ports (COM1/COM2) 2x 3-wire RS-232 ports (COM3/COM4)
Audio	1x 3.5 mm jack for mic-in and speaker-out

Storage Interface
SATA HDD	2x internal SATA port for 2.5″ HDD/ SSD installation, supporting RAID 0/1
M.2	1x M.2 2280 M key NVMe socket (PCIe Gen5x4) for NVMe SSD

Expansion Bus
PCI Express	1x PCIe x16 slot@Gen4, 16-lanes PCIe signal in Cassette for installing NVIDIA® GPU up to 150W (Max. graphics card dimension is 178 mm(L) x 128 mm(W), dual slot allocation)
Mini-PCI Express	2x full-size mini PCI Express socket
Expandable I/O	1x MezIO® expansion port for Neousys MezIO® modules
USB2.0	1x USB 2.0 port with Type-A connector (internal)

Power Supply
DC Input	1x 3-pin pluggable terminal block for 8 to 48V DC input, rated current 20A.
Remote Ctrl. & LED Output	1x 10-pin (2×5) wafer connector for remote on/oﬀ control and status LED output (optional Cbl-W212F-W210F-23CM )

Mechanical
Dimension	240 mm (W) x 225 mm (D) x 111 mm (H)
Weight	3.89 kg
Mounting	Wall-mount (standard) or damping bracket (optional)

Environmental
Operating Temperature	With 35W CPU and 150W GPU -25°C to 60°C[1] With 65W CPU and 150W GPU -25°C to 60°C[1] (configured as 35W TDP) -25°C to 50°C[1] (configured as 65W TDP)
Storage Temperature	-40°C ~ 85°C
Humidity	10%~90% , non-condensing
Vibration	Operating, MIL-STD-810H, Method 514.8, Category 4 (with optional damping bracket)
Shock	Operating, MIL-STD-810H, Method 516.8, Procedure I (with optional damping bracket)
EMC	CE/FCC Class A, according to EN 55032 & EN 55035

1] For sub-zero operating temperature, a wide temperature HDD/ SSD/ NVMe is required.

LIST

Ordering Information

Nuvo-11160GC

Ruggedized Edge AI Platform Supporting 150W GPU and Intel® Core™ Ultra 200S Series Processor

Nuvo-11160GC-PoE

Ruggedized Edge AI Platform Supporting 150W GPU and Intel® Core™ Ultra 200S Series Processor with option of 802.3at PoE+ PSE for 2.5GbE port 3 to port 6

Nuvo-11160GC-PoE-10G

Ruggedized Edge AI Platform with 10GbE Supporting 150W GPU and Intel® Core™ Ultra 200S Series Processor with option of 802.3at PoE+ PSE for 2.5GbE port 3 to port 6

Supported MezIO® Modules

Neousys MezIO® module offers computer signals, power rails and control signals via a high-speed connector. It transforms Neousys embedded systems into application-specific systems with application-oriented I/Os such as RS-232/422/485, isolated DIO and ignition power control.

(Click here for details of compatible MezIO® modules)

Optional Accessories

Dmpbr-Nuvo9160

Identical with Neousys’ patented damping brackets assembly for Nuvo-9160GC, and compatible with Nuvo-11160GC

AccsyBx-Cardholder-11160GC-xx

Nuvo-11160GC GPU bracket kit for selected GPU, Please contact Neousys for more information

Cbl-W212F-W210F-23CM

Cable Wafer 2.0 Female 12P to 10P, Length: 23cm

PA-600W-ENC

600W AC/DC power adapter 24V/25A; cord end terminals for terminal block, operating temperature : -20°C to 70°C
