AMD® EPYC™ 7003 “MILAN” 시리즈를 탑재한 러기드 HPC 서버 (NVIDIA® RTX A6000 / A4500, 2x 10G 및 4x 1G Ethernet, 8~48V DC 입력 지원)


  • Powered by AMD® EPYC™ 7003 series processors, supporting up to 64-core/ 128-thread
  • Supports one NVIDIA® RTX A6000/ A4500 with proprietary heat dissipation
  • Rugged -25°C to 60°C operation for edge applications
  • 2x 10G Ethernet by Intel® X550-AT2 and 4x GbE by Intel® I350-AM4
  • Supports 4x DDR4 RDIMM/ LRDIMM up to 512GB of memory
  • Compact 2U 19″ rack-mount enclosure with only 350mm depth
  • Four easy-swappable 2.5” SATA trays for 7mm HDD/ SSD
  • 8~48V wide-range DC input with built-in ignition power control

RGS-8805GC는 AMD EPYC™ 7003 시리즈 “MILAN” 프로세서를 탑재한 견고한 HPC 서버로, 최대 64코어/128 스레드의 컴퓨팅 성능과 512GB의 메모리 용량을 갖추고 있습니다. 고유한 분할 엔클로저 설계를 활용하여 CPU 및 기타 구성 요소에 매우 효과적인 공기 흐름을 제공하여 현장 배치를 위한 신뢰성 있는 -25°C ~ 60°C 작동을 보장합니다.


RGS-8805GC는 다목적 고급 엣지 AI 애플리케이션을 지원하기 위해 최대 38.7 TFLOPS FP32 또는 309.7 TFLOPS 텐서 성능을 제공하는 하나의 하이엔드 NVIDIA® RTX A6000 또는 A4500 GPU를 호스팅할 수 있습니다. RTX GPU에서 발생하는 열을 효율적으로 방출하기 위해 밀폐된 터널을 만드는 독특한 인클로저 설계가 포함되어 있습니다. RGS-8805GC는 자율 주행, DL 기반 비전 검사, 지능형 비디오 분석과 같은 최신 엣지 AI 애플리케이션을 위한 CPU와 GPU의 탁월한 균형을 제공합니다.


I/O 연결 측면에서 RGS-8805GC에는 5GBASE-T 및 2.5와 역호환되는 고속 데이터 전송을 위한 2개의 10G 이더넷 포트가 있습니다.GBASE-T는 NBASE-T 산업용 카메라와 함께 작동하며, 추가 장치를 연결하기 위한 4개의 기가비트 PoE+ 포트와 4개의 USB 3.1 Gen1 포트, 데이터 스토리지를 위한 4개의 간편한 2.5″ HDD 트레이가 있습니다. 부족한 경우 RGS-8805는 프레임 그래버 또는 GMSL 이미지 캡처 카드와 같은 추가 I/O 카드를 설치하기 위한 2개의 x16 PCIe 슬롯을 제공합니다. RGS-8805GC는 광범위한 DC 입력을 수용하는 몇 안 되는 HPC 서버 중 하나로, 다양한 배포 환경에 적응하는 데 도움이 됩니다.


RGS-8805GC는 설치 공간, 작동 온도 및 전원 공급 장치가 가장 일반적으로 직면하는 문제인 현장에 CPU/GPU 서버를 배포하는 문제를 해결합니다. 에어컨디셔닝이 설치된 환경 외부에 설치할 수 있고 가혹한 환경에서도 작동할 수 있는 견고한 HPC 시스템은 보다 진보된 통신 인프라, 공장 자동화, ADAS 및 V2X 애플리케이션을 위한 새로운 AI 지원 엣지 컴퓨팅의 문을 열어줍니다.



Imagine an HPC server unleashed from an air-conditioned data center room, roaming freely in the field! RGS-8805GC is just that, a rugged HPC server powered by the AMD EPYC™ 7003 series “MILAN” processor with up to 64-core/ 128-thread unparalleled computing power and 512GB memory capacity. Utilizing a unique partitioned enclosure design, it provides a highly effective airflow for CPU and other components to guarantee a reliable -25°C to 60°C operation for field deployment.


To fuel versatile advanced edge AI applications, RGS-8805GC can host one high-end NVIDIA® RTX A6000 or A4500 GPU which provides up to 38.7 TFLOPS FP32 or 309.7 TFLOPS tensor performance. It comes with a unique enclosure design that creates a sealed tunnel to efficiently dissipate the heat generated from the RTX GPU. RGS-8805GC offers an exceptional balance of CPU and GPU for modern edge AI applications, such as autonomous driving, DL-based vision inspection, and intelligent video analytics.


In terms of I/O connectivity, RGS-8805GC has two 10G Ethernet ports for high-speed data transmission that are backward compatible with 5GBASE-T and 2.5GBASE-T to work with NBASE-T industrial cameras; it has another four Gigabit PoE+ and four USB 3.1 Gen1 ports for connecting additional devices; and four easy-swappable 2.5″ HDD trays for data storage. If that’s not enough, RGS-8805 provides two x16 PCIe slots for installing additional I/O cards such as frame grabber or GMSL image capture cards. Not to mention that RGS-8805GC is one of few HPC servers that accept wide-range DC input, helping it to adapt to versatile deployment environments.


RGS-8805GC addresses the challenge of deploying a CPU/ GPU server to the field, where installation space, operating temperature, and power supply are some of the most commonly faced issues. A rugged HPC system that can be installed outside of an air-conditioned environment and capable of operating in harsh environments opens the door to new AI-assisted edge computing for more advanced telecom infrastructure, factory automation, ADAS, and V2X applications.

System Core
Processor AMD® EPYC™ 7003 “Milan” series server CPU, up to 64-core/ 128-thread
Chipset Intel® C246 Platform Controller Hub
Graphics Integrated graphics in ASPEED AST2500 BMC, supporting 1920×1200 resolution
Memory 4x RDIMM/ LRDIMM slots, supporting up to 512GB DDR4-3200
TPM Supports TPM 2.0
TPM Supports TPM 2.0


I/O Interface
10G Ethernet 2x 10GBASE-T ports by Intel® X550-AT2, supporting NBASE-T (5G/ 2.5G)
Gigabit Ethernet 4x GbE ports by Intel I350-AM4
PoE+ IEEE 802.3at PoE+ PSE capability on 4x GbE ports
Video Port 1x VGA port via ASPEED AST2500 BMC
USB 4x USB 3.2 Gen1 (5 Gbps) ports
Serial Port 2x software-programmable RS-232/ 422/ 485 ports


Storage Interface
SATA 4x easy-swappable HDD trays for 2.5″ HDD/ SSD installation
M.2 1x M.2 2280 M key socket (PCIe Gen4 x4) for NVMe SSD


Expansion Bus
PCI Express 1x PCIe x16 slot@Gen4, 16-lanes for RTX A6000/ A4500 installation
2x PCIe x16 slots@Gen4, 8-lanes
M.2 1x M.2 3042/ 3052 B key with dual micro-SIM sockets for 4G/ 5G module
mini-PCIe 2x full-size mini PCI Express sockets with USIM support


Power Supply
DC Input 2x 4-pin 7.62mm pitch pluggable terminal block for 8 to 48V DC input and ignition control input


Dimension 444.4 mm (W) x 350 mm (D) x 88.1 mm (H)
Weight 8.6 Kg(incl. CPU & RDIMM)
Mounting Wall-mount with damping brackets (standard)
Rack-mount (optional)


Operating Temperature -25°C ~ 60°C with 100% CPU/ GPU loading */**
Storage Temperature -40°C ~ 85°C
Humidity 10%~90% , non-condensing
Vibration Operating, MIL-STD-810G, Method 514.6, Category 4
Shock Operating, MIL-STD-810G, Method 516.6, Procedure I, Table 516.6-II
EMC CE/ FCC Class A, according to EN 55032 & EN 55035


* The CPU and GPU loading tests are applied using Passmark® BurnInTest 9.1 with a 225W CPU. Operating temperature degrades with higher CPU TDP. For detailed testing criteria, please contact Neousys Technology
** For sub-zero operating temperature, a wide temperature HDD or Solid State Disk (SSD) is required.


Ordering Information

Wide-temperature fanless GPU computer with NVIDIA® Tesla T4 GPU and Intel® Xeon® E or 9th/ 8th-Gen Core™ CPU with M12 connectors

Optional Accessories

600W AC/DC power adapter 24V/25A; cord end terminals for terminal block, operating temperature : -20°C to 70°C.
