POC-900 Series AMD® Ryzen™ PRO 8640U 초소형 임베디드 컴퓨터 (New!)

AMD® Ryzen™ PRO 8640U 기반의 PoE+ 4개, USB 3.2 4개 및 MezIO® 인터페이스를 탑재한 초소형 임베디드 컴퓨터

POC-900 Series AMD® Ryzen™ PRO 8640U 초소형 임베디드 컴퓨터 (New!)

  • AMD® Ryzen™ PRO 8640U processor 15W-30W TDP with 6C/ 12T
  • 16 TOPs NPU with Ryzen™ AI, 31 TOPs for total SoC
  • Up to 32 GB ECC/ non-ECC DDR5 5600 SDRAM
  • 4x PoE+ GbE & 4x USB 3.2 Gen 2 with screw-lock
  • Dual HDMI™ 2.0b display output, Supporting 3840 x 2160 at 60Hz
  • Front I/O access and DIN-rail mounting design
  • -25°C to 70°C wide temperature operation
  • MezIO® interface for easy function expansion
Overview
Introduction

Neousys의 산업용 Fanless PC POC-900 시리즈는 AMD® Ryzen™ 임베디드 8000 시리즈 플랫폼으로 구동되는 Neousys의 컴팩트 POC 제품군 중 가장 최근에 추가된 제품입니다. 산업용 Fanless PC POC-900 시리즈는 기존 POC-700 및 POC-500 시리즈와 동일한 설치 공간, 치수 및 DIN-레일 장착 디자인을 유지함으로써 기존 설치물과의 호환성을 보장하면서도 성능과 연결성을 크게 업그레이드할 수 있습니다.



AMD® Ryzen™ PRO 8640U 프로세서를 탑재한 산업용 Fanless PC POC-900 시리즈는 POC-500 플랫폼 대비 최대 270%의 성능 향상을 제공합니다. 또한 M2 Gen 4×4 NVMe SSD와 DDR5-5600 메모리를 지원하여 저장 공간과 메모리가 향상되었으며, 까다로운 엣지 AI 및 산업용 애플리케이션에 더 빠른 데이터 액세스와 시스템 응답성이 향상되었습니다.



산업용 Fanless PC POC-900 시리즈는 카메라, 센서 및 제어 시스템과의 연결성을 위해 PoE+가 장착된 4개의 기가비트 이더넷 포트, 3.2 포트 4개, 디지털 입출력(DI/DO) 4개를 제공합니다. 또한 Neousys의 MezIO® 인터페이스를 지원하여 특정 애플리케이션 요구 사항을 충족하는 유연한 입출력 확장이 가능합니다. 차세대 AMD® 성능과 컴팩트하고 견고한 신뢰성을 결합한 산업용 Fanless PC POC-900은 산업 자동화, 엣지 AI 및 머신 비전 배포에 탁월한 컴퓨팅 성능과 다재다능함을 제공하도록 설계되었습니다.



The POC-900 series is the latest addition to Neousys’ compact POC family, powered by the AMD® Ryzen™ embedded 8000 series platform. By retaining the same footprint, dimensions and DIN-rail mounting design as the current POC-700 and POC-500 series, the POC-900 ensures compatibility with existing installations while offering significant performance and connectivity upgrades.



Featuring the AMD® Ryzen™ PRO 8640U processor, the POC-900 offers up to 270% performance improvement over POC-500 platforms. In addition, its storage and memory have been enhanced, with support for M2 Gen 4×4 NVMe SSD and DDR5-5600 memory, they enable faster data access and improved system responsiveness for demanding edge AI and industrial applications.



The POC-900 provides four Gigabit Ethernet ports with PoE+, four USB 3.2 ports, and four digital inputs and outputs (DI/ DO) for connectivity with cameras, sensors, and control systems. In addition, it supports Neousys’ MezIO® interface, allowing flexible I/O expansion to meet specific application requirements. Combining next-generation AMD® performance with compact, rugged reliability, the POC-900 is engineered to deliver exceptional computing power and versatility for industrial automation, edge AI, and machine vision deployments.

#POC-900 Series #산업용PC #Fanless PC #팬리스 컴퓨터 #DDR5 #산업자동화 # 엣지AI #머신비전

Specifications
System Core
Processor AMD® Ryzen™ PRO 8640U CPU

(6C/ 12T, 3.5/ 4.9 GHz, 15W-30W TDP)
Graphics AMD® Radeon RDNA3 Graphics
Memory Up to 32 GB DDR5-5600 SDRAM (one SODIMM socket)
TPM Supports dTPM 2.0



I/O Interface
Ethernet 4x Gb Ethernet ports by Intel® I350-AM4 (with WoL)
PoE+ IEEE 802.3at PoE+ on port #1~ 4

– 32W power budget (with UL certified)

– 100W power budget (maximum)
USB 4x USB 3.2 Gen2x1 (10 Gbps) ports in type-A connectors with screw-lock
Video Port 2x HDMI2.0b, Supporting 3840 x 2160 at 60Hz
Serial Port 1x Software-programmable RS-232/422/485 ports (COM1)

3x 3-wire RS-232 ports (COM2/3/4) or 1x RS-422/485 port (COM2)
Isolated DIO 4-CH isolated DI and 4-CH isolated DO
Audio 1x 3.5 mm jack for mic-in and speaker-out
Storage Interface
  • M.2 M key
1x M.2 2280 M key socket (PCIe Gen4 x4) for NVMe SSD
Expansion Bus
Mini PCI-E 1x full-size mini PCI Express socket (PCIe + USB2) with internal micro SIM socket
Expandable I/O 1x MezIO® expansion interface for Neousys MezIO® modules
Power Supply
DC Input 1x 3-pin pluggable terminal block for 8 to 35V DC input
Remote Ctrl.& LED Output 1x 3-pin pluggable terminal block for remote control and PWR LED output
Mechanical
Dimension 64mm (W) x 116mm (D) x 176mm (H)
92mm (W) x 116mm (D) x 176mm (H) (with fan)
Weight 1.2 kg (fanless) or 1.4 kg (with fan)
Mounting DIN-rail mount (standard) or wall-mount (optional)



Environmental
Operating Temperature -25°C ~ 70°C (15W TDP, fanless)

-25°C ~ 45°C (30W TDP, fanless)

-25°C ~ 70°C (30W TDP, with fan)
Storage Temperature -40°C ~ 85°C
Humidity 10%~90% , non-condensing
Vibration MIL-STD-810H, Method 514.8, Category 4 (with wall-mount)
Shock MIL-STD-810H, Method 516.8, Procedure I (with wall-mount)
EMC CE/FCC Class A, according to EN 55032 & EN 55035
Safety UL 62368-1, IEC 62368-1
Ordering Information
POC-915

AMD® Ryzen™ PRO 8640U Ultra-compact Embedded Computer with 4x PoE+, 4x USB 3.2 and MezIO® Interface

Supported MezIO® Modules

Neousys MezIO® module offers computer signals, power rails and control signals via a high-speed connector. It transforms Neousys embedded systems into application-specific systems with application-oriented I/Os such as RS-232/422/485, isolated DIO and ignition power control.

(Click here for details of compatible MezIO® modules)

Optional Accessories
PA-120W-OW

120W AC/ DC power adapter with 12V, 10A DC output, cord end terminals for terminal block. Operating temperature: -30°C to 60°C

PA-160W-OW

160W AC-DC power adapter, 20V/8A; 18AWG/120cm; cord end terminals for terminal block. Operating temperature : -30°C to 70°C

Cbl-DB9F-3DB9M-15CM

DB9 (Female) to 3x DB9 (Male), length: 15CM for COM2/3/4

Wmkit-H-POC500

Wall-mount assembly for POC-500/700/900 series, horizontal type

Wmkit-V-POC500

Wall-mount assembly for POC-500/700/900 series, vertical type

AccsyBx-FAN-POC-900

Fan assembly for POC-900 series, 92x92x25 mm
