GPU Workstation - Intel® Xeon® W-3500/2500/3400/2400
BMS W773-W80
- Supports up to 4 x Dual slot Gen5 GPUs
- Single Intel® Xeon® W-3500/3400 Processors
- Single Intel® Xeon® W-2500/2400 Processors
- 8-Channel DDR5 RDIMM, 8 x DIMMs
- Intel® W790 Chipset
- 2 x 10Gb/s LAN ports via Intel® X710-AT2
- 2 x M.2 slots with PCIe Gen4 x4 interface
- Up to 8 x 3.5"/2.5" SATA bays
- 5 x PCIe Gen5 x16 slots
- 2 x PCIe Gen4 x16 slots
- Single 2000W ATX 80 PLUS Gold power supply
Specifications
|
|
|---|---|
| Chassis Form Factor |
|
| Serverboard |
|
| PSU Form Factor |
|
| Drive Backplane |
Front hot-swap: 4 x 3.5″/2.5″ SATA Optional 4 x 3.5″/2.5″ SATA |
| Hot-swap Drive Bays |
|
| Cooling Fans |
Rear: 1 x 120x120x25mm
|
| Temperature Control |
|
| Expansion Slots |
2 x PCIe x16 (Gen4 x16) slots
2 x M.2 (2280), PCIe Gen4 x4, from PCH
|
| Indicator |
Front I/O: 2 x USB 3.2 Gen1 ports (Type-A), 2 x Audio jacks (Audio out/Mic), 1 x Power button, 1 x Reset button, 1 x Power LED, 1 x Storage activity LED, 1 x System status LED Rear I/O: 1 x USB 3.2 Gen2x2 port (Type-C), 3 x USB 3.2 Gen2x1 ports (Type-A), 1 x VGA port, 1 x COM port, 2 x RJ45 ports, 1 x MLAN port, 3 x Audio jacks (Audio in/Audio out/Mic), 1 x ID button with LED |
| Weight |
|
| Chassis Dimensions (WxHxD, mm) |
|
